UNI-T UTi720B Thermal Imager with Macro Lens Comb

SKU: UTI7202
Rs. 35,500.00 MRP Rs. 42,000.00 Save Rs. 6,500.00 (16% off) Inclusive of GST-18%
In Stock (10 available) Delivery 2-6 days MOQ 1 piece
Quantity to add

SUPER COMBO- Ideal for electronic and electrical diagnostic.

UTi720B is a featured product of UNI-T heavy duty series thermal cameras. It is cost effective and with a wide temperature range: -20℃~550℃. It has higher IR resolution: 256×192 pixels than other models, and includes 7 color palettes and four display modes: thermal, visual image, fusion, and picture in picture.  It is also user friendly and rugged enough to pass IP65 and 2m drop test.

Features :

  • Durable and user-friendly
  • 2.8” TFT display screen (320×240 Pixels), IR resolution: 256×192. Digital camera resolution: 640×480
  • Temperature measurement range: -20℃ to 550℃ / -4℉ to 1022 ℉
  • Features T-Mix image fusion algorithm technology
  • Video recording
  • With a 2MP digital camera
  • Wi-Fi connection
  • Multi-language OS
  • IP65 & 2m drop proof

UT-Z002 is a macro lens which fits the UNI-T thermal cameras UTi260B, UTi720A. It is a perfect auxiliary adaptor of thermal cameras that can find tiny electrical components which are overheating and help engineers to complete circuit load and temperature analysis,quickly identify the fault points

ToolWorld is Authorized UNI-T Distributor

Includes calibration/conformity report

Product information

Everything you need to know

Technical Specifications

Display 2.8” TFT (320×240)

IR resolution(Pixels)      256×192

Super resolution(Pixels)              √ (512×384)

Spectral range 8~14µm

Pixel size             12µm

Frame rate         ≤25Hz

Thermal sensitivity(NETD)         ≤50mK

Focus   Focus Free

Field of view(FOV)          56°(H) × 42°(V)

Spatial resolution(IFOV)             3.75mrad

Temperature measurement range         -20℃~550℃

Accuracy            20℃~120℃, ±1.5℃ or ±1.5% whichever is greater

-10℃~20℃, 120℃~550℃, ±2℃ or ±2% whichever is greater

Warranty
As per Brand policy

Recommended Uses

Product Development, Electric Maintenance, Digital products evaluation
